Requirements for Customized Communication Cable Trays

Communication cable trays must comply with NEC standards, maintain proper fill and separation, be made of suitable materials, and allow safe grounding and accessibility.Cable Tray Types and Materials

Communication cable trays can be metallic (steel, aluminum) or nonmetallic (fiberglass, FRP), and are available in various styles such as ladder, ventilated trough, wire mesh, channel, and solid-bottom trays . Material selection depends on environmental conditions, load requirements, and corrosion resistance. Aluminum is preferred for its corrosion resistance, while steel provides higher mechanical strength .

Cable Types and Ratings

Only conductors rated for open-air environments should be installed in trays, including Tray Rated (Type TC), Metal-Clad (Type MC), and Power-Limited Tray Cable (PLTC) . Single insulated conductors of 1/0 AWG or larger can be used in industrial setups. Communication and signal cables must be compatible with tray installation and avoid overheating.

Fill Capacity

The NEC specifies maximum fill limits to ensure proper airflow and prevent overheating. For communication and control cables, the fill should not exceed 50% of the tray's cross-sectional area . Overfilling can restrict airflow, increase heat buildup, and cause mechanical damage.

Separation and Electromagnetic Interference

High-power and low-power cables must be physically separated to prevent electromagnetic interference (EMI). Dividers or separate trays are recommended when power and communication cables run in parallel . Proper spacing ensures signal integrity and reduces the risk of data corruption.

Grounding and Bonding

Metallic trays can serve as equipment grounding conductors (EGC) if they are electrically continuous and properly bonded at all splice points . Bonding jumpers may be required where mechanical connections do not provide reliable continuity. Proper grounding prevents shock hazards and ensures compliance with NEC requirements.

Installation and Accessibility

Cable trays must be accessible for maintenance, with at least 12 inches of vertical clearance above the tray for installation and servicing . Trays cannot be installed in hoistways or enclosed spaces. Rung spacing of 6 to 9 inches is recommended for ladder or channel trays to support cables and maintain bend radius . Solid-bottom trays are suitable for areas with minimal heat buildup and where visual aesthetics are important.

Firestopping and Penetrations

When trays penetrate fire-rated walls, floors, or plenum spaces, approved firestop systems must be used to maintain the building's fire-resistance rating . This prevents the spread of fire, smoke, and heat through penetrations.

Standards and References

Key standards and guidelines include:

• NEC Article 392: Installation, fill, grounding, and separation requirements
• NEMA VE 1 and VE 2: Construction, testing, and performance of metallic and nonmetallic trays
• UL 568: Performance requirements for fiberglass cable trays
• IEC 61537: International standard for cable tray systems Following these requirements ensures safe, reliable, and code-compliant installation of communication cable trays in industrial and commercial facilities.
